| Model | JH18AN-32D3-2 | JH18AN-32T3-2 | JH18AN-32S3-2 |
|---|---|---|---|
|
Airflow(m3/h)
|
18,000
|
18,000
|
18,000
|
|
Power(KW)
|
1.1
|
1.1
|
1.1
|
|
Speed
|
2
|
2
|
2
|
|
Pressure(Pa)
|
180
|
180
|
180
|
|
Fan Type
|
Axial
|
Axial
|
Axial
|
|
Water Tank(L)
|
30
|
30
|
30
|
|
Noise(dB(A))
|
≦73
|
≦73
|
≦73
|
|
Water Consumption(L/H)
|
15-20
|
15-20
|
15-20
|
|
Net Weight(Kg)
|
77
|
78
|
107
|
|
Coverage(m2)
|
100-150
|
100-150
|
100-150
|
|
Dimension(mm)
|
1160*1160*990
|
1160*1160*940
|
116*1240*900
|
|
Operating Weight(Kg)
|
120
|
120
|
120
|
|
Air Discharge
|
Down
|
Top
|
Side
|
|
Vent size(mm)
|
675x675
|
675x675
|
660-660
|
|
Control type
|
LED+Remote
|
LED+Remote
|
LED+Remote
|
|
Auto water drain
|
yes
|
yes
|
yes
|
|
Overload protection
|
yes
|
yes
|
yes
|
|
Pump protection
|
yes
|
yes
|
yes
|
|
Thermostatic
|
Option
|
Option
|
Option
|
|
Shut down clean
|
Option
|
Option
|
Option
|
|
Pre-dust filter
|
Option
|
Option
|
Option
|
|
Pre-cooling
|
Option
|
Option
|
Option
|
|
Group control
|
Option
|
Option
|
Option
|
